⚙️ Features
- One-way automatic shut-off valve in the socket.
- Wide variety provides best choice accordingly to application.
- Hardened important parts are extremely wear resistant and durable.
- Tested 100,000 times, coupler connection is accurate and reliable.
⚙️ Application
Pneumatic tools、Air piping、Air pressure equipment
⚙️ Specification
Part No.
|
20 SP | 30 SP | 40 SP | 45 SP | 50 SP |
Hose Size
|
5 x 8 mm | 6.5 x 10 mm | 8 x 12 mm | 10 x 14 mm | 11 x 16 mm |
Thread
|
PT | ||||
Working Pressure
|
218 PSI (15 Bar / 1.5 MPa) | ||||
Maximum Pressure
|
290 PSI (20 Bar / 2 MPa) | ||||
Temperature Range
|
-20 ℃ ~ +80 ℃ |
