⚙️ Features
- Improved operation.
- Chrome plated steel body for anti-corrosion.
- One-touch series couplers could be widely applied for male and female thread connections, hose connectors and manifolds.
⚙️ Application
Pneumatic tools、Air piping、Air pressure equipment
⚙️ Specification
|
Part No.
|
20 SPT
|
30 SPT
|
40 SPT
|
45 SPT
|
50 SPT
|
|---|---|---|---|---|---|
|
Hose Size
|
5 x 8 mm
|
6.5 x 10 mm
|
8 x 12 mm
|
10 x 14 mm
|
11 x 16 mm
|
|
Thread
|
PT | ||||
|
Working Pressure
|
218 PSI (15 Bar / 1.5 MPa) | ||||
|
Maximum Pressure
|
290 PSI (20 Bar / 2 MPa) | ||||
|
Temperature Range
|
-20 ℃ ~ +80 ℃ | ||||
